Display Panel

LCD liquid-crystal display screen

Power-on Self-diagnosis Function

(1)The system automatically checks and diagnoses whether the equipment operates normally upon power-on(2)The LCD screen automatically displays fault information in case of system failure

Operation System

(1)Chinese / English menu selection function(2)Remote network operation via computer (Optional)(3)User-friendly interactive human-machine interface with Windows-style layout

Pass-through Speed

1~100 persons per minute; detection speed is customizable

Backlight Duration

Continuously adjustable display time from 0~99s

Calendar Clock

Displays year, month, date, hour and minute

Detection Zones

5 detection zones; precise single-zone or multi-zone alarm configurable as required

Zone Performance

(1)Detection zones divided according to human-body structure(2)Self-transmit-and-receive detection to locate prohibited knives and other articles(3)Single-frequency excitation technology creates highly uniform magnetic-field density within detection zones(4)Strong penetration, high detection sensitivity and stable performance

Alarm Indication

(1)1~25s adjustable alarm duration; 255-level continuous volume adjustment(2)LED pillar lamps on front and rear door pillars directly show alarm zones, accurately indicating contraband height position on human body

Sensitivity Adjustment

(1)Each detection zone supports 255-level sensitivity adjustment (three working modes for different scenarios)(2)Preset weight, volume, size and position of metallic articles to eliminate false alarms caused by coins, keys, jewelry, belt buckles, etc.

Anti-interference Performance

(3)Adopts advanced interactive transmitting & receiving technology(4)Automatic temperature-humidity detection, tracking and compensation technology adapts to diverse environments and climates for enhanced anti-interference capability(5)Adjustable frequency range: 4K~8K to avoid mutual interference from external equipment operating at similar frequencies

Safety Performance

(1)Dual-level password protection; accessible only to authorized personnel for higher security(2)Factory-setting restoration available for system errors caused by incorrect user configuration(3)Uninterruptible power-supply protection system; 2~8-hour battery power supply with parameter protection during power failure (Optional)(4)Harmless to cardiac pacemaker wearers, pregnant women, magnetic disks and magnetic tapes

Linkage Function (Standard)

Supports linkage with access-control systems such as turnstiles, facial-recognition devices, camera systems and temperature-screening systems for seamless integration

Counting Function

Intelligent passenger-flow and alarm counting. Automatically counts pass-through personnel and alarm events. Radar human-body sensor replaces infrared sensor to eliminate blind-spot errors caused by different-colored clothing

Backup Battery

Optional lithium-ion backup battery; over 8-hour continuous operation after full charge (Optional)

Application Scenarios

Scene modes configurable on-site for airports, entertainment venues, courts and other locations

Human-body Safety

Harmless to pacemaker wearers and other life-support devices, pregnant women, magnetic disks, magnetic tapes and video tapes

Model

WD-300U

Detection Zones

5 independent detection zones

Overall Sensitivity

0~255 levels

Pass-through Speed

0.4M/S~1.2M/S

Power Consumption

＜20W

Frequency Bands

1~100 bands

Compliant Standard

GB15210-2003

Total Weight

Approx. 35kg

Operating Ambient Temperature

-20℃ ~ +45℃

Operating Voltage

AC85V-264V, 50/60Hz

Inner Passage Dimension

2000(H) × 800(Single-sided detection width) × 400(D) mm

Overall External Dimension

2000(H) × 400(W) × 120(Thickness) mm
